Media: | Water | Material: | Stainless Steel |
---|---|---|---|
Type: | Fixed Ball Valve | Standard: | 3A,DIN,SMS, |
Application: | Water Industrial Usage | Specification: | 1/4"-4" |
High Light: | 0.5inch stainless steel sanitary ball valve,water stainless steel sanitary ball valve,sanitary 0.5 stainless steel ball valve |
Process: | Raw material,investment casting,inspection, test,cleaning,laser,package |
Connection type: | Welding, Tri Clamp,Flange,Union |
Size: | 1/2'' - 4'' |
Temperature Range: | -20°C~135°C |
Suitable medium: | Water, oil, steam, nitric, acid, acetate acid and some corrosive liquids |
Main material: | Stainless steel 304, 316 |
Type | two way,three way |
Operate | Manual,pneumatic or electric |
Body Type | Two piece,three piece |
Working Pressure | 0~10 bar |
Seal Material | PTFE |
Character | 1. The valve body material can only be made of 304ss304L or 316316L stainless steel, and industrial ball valves can be made of cast iron, cast steel, ductile iron, stainless steel and other materials. 2. The appearance is polished by standard sanitary ball valve standard electronic, to achieve a smooth surface and ensure clean, no medium accumulation area, no potential pollution. 3. The linking method generally adopts the method of quick installation of clamp and thread; the connection method of industrial ball valve includes flange, thread, quick installation and welding. 4. The fluid resistance is small, and the resistance coefficient is equal to that of the pipe section of the same length. 5. Simple structure, small size and light weight. 6. Convenient operation, quick opening and closing, only need to rotate 90° from fully open to fully closed. 7. Convenient maintenance, simple structure of ball valve, seal ring is generally movable, disassembly and replacement are more convenient. 8. When fully open or fully closed, the sealing surfaces of the ball and the valve seat are isolated from the medium. When the medium passes through, it will not cause corrosion of the valve sealing surface. 9. A wide range of applications, from small diameter to a few millimeters, to a few meters, from high vacuum to high pressure can be applied. |
Application | Pharmacy,beer,food,dairy beverage,cosmetic and etc. |
