Technics: | Casting | Material: | Malleable Iron |
---|---|---|---|
Specification: | 1/2"-6" | Connection: | Female |
Type: | Eblow,tee, Coupling | Shape: | Equal |
High Light: | plain end malleable iron fittings,bs thread malleable iron fittings,1inch malleable pipe fittings |
SPECIFICATION
Material | Malleable iron |
Standard | Thread: ISO 7/1 |
Dimension: ISO 49, DIN 2950,EN10242 | |
Chemical property | (C %2.4-2.9), (Si %1.4-1.9), (Mn %0.4-0.65), (P% <0.1), (S% <0.2%) |
Physical property | Tensile strength>=350Mpa,Elongation>=10% Hardness<=150HB |
Testing pressure | 2.5Mpa |
Working pressure | 1.6Mpa |
Type | Beaded with ribs or banded with ribs |
Beaded without ribs or banded wihtout ribs | |
Round/square | |
Surface | Galvanized/ no galvanized |
Color | White/black |
Model | Elbow, Tees, Crosses, Bends, Unions, Bushings, Lateral Braches, Sockets, Nipples, Hexagon/Round, Caps, Plugs, Locknuts, Flanges ,Side Outlet Tees, Side Outlet Elbows and etc |
Connection | Male, Female |
Shape | Equal, Reducing |
Certificate | BSI,ANAB,ISO9001,FM,UL |
Application | Suitable for pipe connect of steam, air, gas, oil and so on |
Buyer’s drawings or designs are available | |
Package | Cartons without pallet |
Cartons with pallet | |
Double woven bags | |
Or as buyer’s requirements | |
Delivery details | According to the quantities and specifications of each order |
Normal delivery time is from 30 to 45 days after receiving the deposit |
